Customized Flash Drying Solution for High-Viscosity Materials

For paste-like, filter cake-like and other high-viscosity materials prone to caking, we break through the limitations of traditional drying and provide a dedicated flash drying solution:

1. Simultaneous Dispersing and Drying Technology: A high-speed dispersing device is built into the drying tower to instantly break caked materials into fine particles, which are then quickly dried with high-temperature hot air to avoid agglomeration;

2. Optimized Hot Air Flow Field Design: Using tangential air intake and a swirling hot air distributor to form a spiral upward air flow, allowing materials to fully contact hot air in a suspended state for uniform drying without dead corners;

3. Anti-Sticking Wall Structure Design: Air sweeping devices and anti-sticking liners are installed on the tower wall, combined with a reasonable tower height-to-diameter ratio design, which greatly reduces the risk of material adhesion;

4. Customized Process Parameters: Adjust the spindle speed, inlet air temperature and air volume according to the material viscosity and moisture content, with a moisture content control accuracy of ±0.5% to meet customers' finished product requirements.
