WH series trough mixer is used to mix powdery or wet materials to make different proportions of main and auxiliary materials mix evenly. The contact between the machine and materials is made of stainless steel. The gap between the paddle and the barrel body is small, and there is no dead angle for mixing. Sealing devices are set at both ends of the mixing shaft to prevent the outward leakage of materials. The hopper is controlled by button inching, which is convenient for discharging. It is widely used in pharmaceutical, chemical, food and other industries.
WH series trough mixer is used to mix powdery or wet materials to make different proportions of main and auxiliary materials mix evenly. The contact between the machine and materials is made of stainless steel. The gap between the paddle and the barrel body is small, and there is no dead angle for mixing. Sealing devices are set at both ends of the mixing shaft to prevent the outward leakage of materials. The hopper is controlled by button inching, which is convenient for discharging. It is widely used in pharmaceutical, chemical, food and other industries.
● This machine is used for mixing dry material particles in pharmaceutical, chemical, food, metallurgy and other industries.
| Specifications / Items | Total volume (L) | Working volume (L) | Charging capacity (kg) | Charging speed (rpm) | Power (kW) | Weight (kg) |
| 0.05 | 50 | 25 | 15 | 25 | 0.55 | 500 |
| 0.15 | 150 | 75 | 45 | 20 | 0.75 | 650 |
| 0.3 | 300 | 150 | 90 | 20 | 1.1 | 820 |
| 0.5 | 500 | 250 | 150 | 18 | 1.5 | 1250 |
| 1 | 1000 | 500 | 300 | 15 | 3 | 1800 |
| 1.5 | 1500 | 750 | 450 | 12 | 4 | 2100 |
| 2 | 2000 | 1000 | 600 | 12 | 5.5 | 2450 |
| 3 | 3000 | 1500 | 900 | 9 | 5.5 | 2980 |
| 4 | 4000 | 2000 | 1200 | 9 | 7.5 | 3300 |
| 5 | 5000 | 2500 | 1500 | 8 | 7.5 | 3880 |
| 6 | 6000 | 3000 | 1800 | 8 | 11 | 4550 |
| 8 | 8000 | 4000 | 2400 | 6 | 15 | 5200 |
| 10 | 10000 | 5000 | 3000 | 6 | 18.5 | 6000 |
