Building block structure, less land occupation, no open dust points, centralized dust removal and small environmental load
Building block structure, less land occupation, no open dust points, centralized dust removal and small environmental load
Through system optimization, the process flow is simple and smooth, the operation is reliable, and the labor cost is saved at the same time;
High degree of automation, convenient operation, maintenance and installation:
Stable product quality, strong adaptability of raw materials, flexible and convenient parameter adjustment:
The perfect fine powder recovery system can effectively reduce the fine powder content and mud content of the finished products. At the same time, the company can provide a variety of high value-added comprehensive utilization schemes of fine powder.
The loader shovels the raw materials into the bucket and sends them to the crusher by frequency conversion belt.
The crusher adopts centrifugal impact crusher, which is based on the principle of centrifugal belt, animal material and body lining plate impact, and material and material impact, so that the material particles of the crusher are round and the steel distribution is reasonable.
The crushed materials enter the circular vibrating screen through the plate chain elevator. The circular vibrating screen adopts a fully enclosed structure. The dust collector is directly connected with the screen to form a negative pressure state. The original dust is lifted out. The materials on the screen return to the crusher through the plate chain elevator for recycling and crushing, and the finished products enter the cyclone separator through the plate chain elevator.
After the materials enter the fine powder separator, the deflector disperses the materials in the form of gravity parabola. Under the action of the wind speed of the induced draft fan, the fine powder is separated. The induced air volume can be adjusted according to the thickness of the fine powder and the amount of powder. The dust is discharged from the outlet at the top of the powder selection under the action of the fan. After the gas powder is separated by the pulse bag dust collector, it enters the tank for storage. The recovered fine powder is stored in the tank and can be loaded into the tank truck for takeout through the bulk container. The finished materials shall be measured, mixed and packaged.
| Model | WZ-0.05 | WZ-0.1 | WZ-0.3 | WZ-0.5 | WZ-1 | WZ-2 | WZ-3 | WZ-4 | WZ-6 |
| Primary mixing | 21–30 | 40–60 | 120–180 | 200–300 | 400–600 | 800–1200 | 1200–1600 | 1600–2400 | 2400–3600 |
| Installed power | 2.2 | 3 | 4–5.5 | 5.5–7.5 | 7.5–11 | 11–15 | 18.5–22 | 22–30 | 30–37 |
